5.3.2 Operator controls of the discharge belt 1

1 Adjusting wheel on the pressure roller line module (height adjustment)
42
Note!
The illustration of the discharge belt includes the pressure roller line
module.
Note!
The illustration of the pressure roller resembles the version that is
delivered. The version that is delivered may include a hand guard and a
flexible shaft to move the adjusting wheel to operate the adjustment
mechanism, which are not shown here.
