5.2.3 Function elements of the pressure roller

1 Holder
2 Pressure roller
Emil Kemper GmbH
Note!
The illustration of the pressure roller line module resembles the version
that is delivered. The version that is delivered may include a hand guard
and a flexible shaft to move the adjusting wheel to operate the adjustment
mechanism, which are not shown here.
EVOLUTION LINE roll machine
3 Pressure roller adjustment mechanism
27
