Overview of the line

5 Overview of the line
This chapter presents the assemblies with their modules as well as the line's function
elements and operator controls.

5.1.1 Overview of the basic module assembly

The following illustration displays configuration of the assembly modules
Basic module on the left in running direction:
1 Drive frame and intermediate proofer
2 Centring unit (optional)
Emil Kemper GmbH
Note!
For the head machine, details about this chapter can be found in the
separate user manual of the head machine.
EVOLUTION LINE roll machine
3 Discharge belt with pressure roller
