2.6

Internal View

WARNING:
Only authorized Delta engineers or service personnel can perform
installation, wiring, panel & cover removal, maintenance and operation. If you
want to execute any action mentioned above by yourself, the action must be
under the supervision of authorized Delta engineers or service personnel.
After you open the UPS's front door, you will see the internal mechanisms including
communication interfaces, five power module slots (among which, only the top three
slots have covers), an STS module and four breakers (Input/ Bypass/ Manual Bypass/
Output). Please refer to Figure 2-4.
Delta UPS DPH 50-200kVA
Figure 2-3: How to Open the UPS Front Door
