:SBUS<n>:I2S:SOURce:WSELect
Command Syntax
:SBUS<n>:I2S:SOURce:WSELect <source>
<source> ::= {CHANnel<n> | EXTernal} for the DSO models
<source> ::= {CHANnel<n> | DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels) in NR1 format
<d> ::= 0 to (# digital channels - 1) in NR1 format
The :SBUS<n>:I2S:SOURce:WSELect command controls which signal is used as
the word select (WS) source by the serial decoder and/or trigger when in I2S
mode.
Query Syntax
:SBUS<n>:I2S:SOURce:WSELect?
The :SBUS<n>:I2S:SOURce:WSELect? query returns the current source for I2S
word select (WS).
Return Format
<source><NL>
See Also •
•
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
"Introduction to :TRIGger Commands"
":SBUS<n>:I2S:SOURce:CLOCk"
":SBUS<n>:I2S:SOURce:DATA"
on page 1139
on page 849
on page 850
