:MARKer Commands

:MARKer:XDELta

Query Syntax
:MARKer:XDELta?
The MARKer:XDELta? query returns the value difference between the current X1
and X2 cursor positions.
Xdelta = (Value at X2 cursor) - (Value at X1 cursor)
X cursor units are set by the :MARKer:XUNits command.
If the front-panel cursors are off, the marker position values are not defined. Make sure to set
NOTE
:MARKer:MODE to MANual or WAVeform to put the cursors in the front-panel Normal mode.
Return Format
<value><NL>
<value> ::= difference value in NR3 format.
See Also •
•
•
•
•
•
•
462
(see page 1428)
"Introduction to :MARKer Commands"
":MARKer:MODE" on page 455
":MARKer:X1Position"
":MARKer:X2Position"
":MARKer:X1Y1source"
":MARKer:X2Y2source"
":MARKer:XUNits" on page 463
on page 453
on page 457
on page 460
on page 458
on page 461
