:SBUS<n> Commands
:SBUS<n>:LIN:SYNCbreak
Command Syntax
:SBUS<n>:LIN:SYNCbreak <value>
<value> ::= integer = {11 | 12 | 13}
The :SBUS<n>:LIN:SYNCbreak command sets the length of the LIN sync break to
be greater than or equal to 11, 12, or 13 clock lengths. The sync break is the idle
period in the bus activity at the beginning of each packet that distinguishes one
information packet from the previous one.
Query Syntax
:SBUS<n>:LIN:SYNCbreak?
The :SBUS<n>:LIN:SYNCbreak? query returns the current LIN sync break setting.
Return Format
<value><NL>
<value> ::= {11 | 12 | 13}
See Also •
•
•
•
880
(see page 1428)
"Introduction to :TRIGger Commands"
":TRIGger:MODE" on page 1148
":SBUS<n>:LIN:SIGNal:DEFinition"
":SBUS<n>:LIN:SOURce"
on page 1139
on page 1378
on page 878
