:MEASure Commands
Table 105 :MEASure Commands Summary (continued)
Command
:MEASure:XMAX
[<source>] (see
page 552)
:MEASure:XMIN
[<source>] (see
page 553)
Introduction to The commands in the MEASure subsystem are used to make parametric
:MEASure measurements on displayed waveforms.
Commands
Measurement Setup
To make a measurement, the portion of the waveform required for that
measurement must be displayed on the oscilloscope screen.
Measurement Type
period, duty cycle, or frequency
pulse width
rise time
fall time
Measurement Error
488
Query
:MEASure:XMAX?
[<source>] (see
page 552)
:MEASure:XMIN?
[<source>] (see
page 553)
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
Options and Query Returns
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
Portion of waveform that must be d isplayed
at least one complete cycle
the entire pulse
rising edge, top and bottom of pulse
falling edge, top and bottom of pulse
