:POWer:CLResponse:WGEN:LOAD

Command Syntax
:POWer:CLResponse:WGEN:LOAD <impedance>
<impedance> ::= {ONEMeg | FIFTy}
The :POWer:CLResponse:WGEN:LOAD command sets the waveform generator
expected output load impedance.
The output impedance of the Gen Out signal is fixed at 50 ohms. However, the
output load selection lets the waveform generator display the correct amplitude
and offset levels for the expected output load. If the actual load impedance is
different than the selected value, the displayed amplitude and offset levels will be
incorrect.
Query Syntax
:POWer:CLResponse:WGEN:LOAD?
The :POWer:CLResponse:WGEN:LOAD? query returns the waveform generator
expected output load impedance setting.
Return Format
<impedance><NL>
<impedance> ::= {ONEM | FIFT}
See Also •
•
•
•
•
•
•
•
•
•
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
":POWer:CLResponse"
":POWer:CLResponse:APPLy"
":POWer:CLResponse:DATA"
":POWer:CLResponse:FREQuency:MODE"
":POWer:CLResponse:FREQuency:STARt"
":POWer:CLResponse:FREQuency:STOP"
":POWer:CLResponse:PPDecade"
":POWer:CLResponse:SOURce:INPut"
":POWer:CLResponse:SOURce:OUTPut"
":POWer:CLResponse:WGEN:VOLTage"
":POWer:CLResponse:WGEN:VOLTage:PROFile"
on page 626
on page 627
on page 628
on page 629
on page 630
on page 631
on page 632
on page 633
on page 634
on page 636
:POWer Commands
on page 637
