:MEASure:DUAL:VAMPlitude

Overview This measurement is available with the N2820A high sensitivity current probe
when both the Primary and Secondary probe cables are used. This measurement
joins the Zoom In waveform data below the probe's clamp level with Zoom Out
waveform data above the probe's clamp level to create the waveform on which the
measurement is made.
Command Syntax
:MEASure:DUAL:VAMPlitude [<source1>][,<source2>]
<source1>,<source2> ::= CHANnel<n> with N2820A probe connected
<n> ::= 1 to (# analog channels) in NR1 format
The :MEASure:DUAL:VAMPlitude command installs a screen measurement and
starts a vertical amplitude measurement.
If the optional source parameter(s) are specified, the currently specified source(s)
are modified.
Query Syntax
:MEASure:DUAL:VAMPlitude? [<source1>][,<source2>]
The :MEASure:DUAL:VAMPlitude? query measures and returns the vertical
amplitude of the waveform. To determine the amplitude, the instrument measures
Vtop and Vbase, then calculates the amplitude as follows:
Return Format
<value><NL>
<value> ::= the amplitude of the selected waveform in NR3 format
See Also •
•
•
•
•
•
•
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
vertical amplitude = Vtop - Vbase
":MEASure:DUAL:CHARge"
":MEASure:DUAL:VAVerage"
":MEASure:DUAL:VBASe"
":MEASure:DUAL:VPP"
":MEASure:DUAL:VRMS"
"Introduction to :MEASure Commands"
":MEASure:SOURce" on page 529
":MEASure:VTOP" on page 550
on page 502
on page 504
on page 505
on page 506
on page 507
on page 488
