:SBUS<n>:SPI:SOURce:FRAMe
Command Syntax
:SBUS<n>:SPI:SOURce:FRAMe <source>
<source> ::= {CHANnel<n> | EXTernal} for the DSO models
<source> ::= {CHANnel<n> | DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels) in NR1 format
<d> ::= 0 to (# digital channels - 1) in NR1 format
The :SBUS<n>:SPI:SOURce:FRAMe command sets the frame source when
:SBUS<n>:SPI:FRAMing is set to CHIPselect or NOTChipselect.
Query Syntax
:SBUS<n>:SPI:SOURce:FRAMe?
The :SBUS<n>:SPI:SOURce:FRAMe? query returns the current frame source for the
SPI serial frame.
Return Format
<source><NL>
See Also •
•
•
•
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
"Introduction to :TRIGger Commands"
":SBUS<n>:SPI:SOURce:CLOCk"
":SBUS<n>:SPI:SOURce:MOSI"
":SBUS<n>:SPI:SOURce:MISO"
":SBUS<n>:SPI:FRAMing"
on page 1139
on page 936
on page 939
on page 938
on page 935
29
:SBUS<n> Commands
937
