:SBUS<n> Commands
:SBUS<n>:M1553 Commands
These commands are valid when the DSOX4AERO MIL-STD-1553 and ARINC 429 triggering
NOTE
and serial decode option (Option AERO) has been licensed.
Table 120 :SBUS<n>:M1553 Commands Summary
Command
:SBUS<n>:M1553:AUTose
page 891)
tup (see
:SBUS<n>:M1553:BASE
page 892)
<base> (see
:SBUS<n>:M1553:SOURce
<source> (see
page 893)
:SBUS<n>:M1553:TRIGge
r:PATTern:DATA
<string> (see
page 894)
:SBUS<n>:M1553:TRIGge
r:RTA <value> (see
page 895)
:SBUS<n>:M1553:TRIGge
r:TYPE <type> (see
page 896)
890
Query
n/a
:SBUS<n>:M1553:BASE?
page 892)
(see
:SBUS<n>:M1553:SOURce
page 893)
? (see
:SBUS<n>:M1553:TRIGge
r:PATTern:DATA? (see
page 894)
:SBUS<n>:M1553:TRIGge
page 895)
r:RTA? (see
:SBUS<n>:M1553:TRIGge
page 896)
r:TYPE? (see
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
Options and Query Returns
n/a
<base> ::= {BINary | HEX}
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
<string> ::= "nn...n" where n ::=
{0 | 1 | X}
<value> ::= 5-bit integer in
decimal, <nondecimal>, or
<string> from 0-31
<nondecimal> ::= #Hnn where n ::=
{0,..,9|A,..,F}
<string> ::= "0xnn" where n::=
{0,..,9|A,..,F}
<type> ::= {DSTArt | DSTOp |
CSTArt | CSTOp | RTA | PERRor |
SERRor | MERRor | RTA11}
