:SBUS<n>:USB:TRIGger:ADDRess
Command Syntax
:SBUS<n>:USB:TRIGger:ADDRess <string>
<string> ::= "nnnnnnn" where n ::= {0 | 1 | X}
<string> ::= "0xnn" where n ::= {0,..,9 | A,..,F | X | $}
The :SBUS<n>:USB:TRIGger:ADDRess command specifies the 7-bit Address
portion of the trigger for the selected bus, in binary or hex.
Query Syntax
:SBUS<n>:USB:TRIGger:ADDRess?
The :SBUS<n>:USB:TRIGger:ADDRess? query returns the specified Address
portion of the trigger.
Return Format
<string><NL>
<string> ::= "nnnnnnn" where n ::= {0 | 1 | X}
See Also •
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
":SBUS<n>:USB:TRIGger:PID:SPECial"
":SBUS<n>:USB:TRIGger:PID:TOKen"
:SBUS<n> Commands
on page 988
on page 989
