:MEASure:VBASe

Command Syntax
:MEASure:VBASe [<source>]
<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | WMEMory<r>}
<n> ::= 1 to (# analog channels) in NR1 format
<m> ::= 1 to (# math functions) in NR1 format
<r> ::= 1 to (# ref waveforms) in NR1 format
The :MEASure:VBASe command installs a screen measurement and starts a
waveform base value measurement. If the optional source parameter is specified,
the current source is modified.
This command is not available if the source is FFT (Fast Fourier Transform).
NOTE
Query Syntax
:MEASure:VBASe? [<source>]
The :MEASure:VBASe? query returns the vertical value at the base of the
waveform. The base value of a pulse is normally not the same as the minimum
value.
Return Format
<base_voltage><NL>
<base_voltage> ::= value at the base of the selected waveform in
See Also •
•
•
•
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
NR3 format
"Introduction to :MEASure Commands"
":MEASure:SOURce" on page 529
":MEASure:VTOP" on page 550
":MEASure:VAMPlitude"
":MEASure:VMIN" on page 545
on page 488
on page 541
