Trigger[:Edge]:Level - Keysight Technologies InfiniiVision MSO-X 4022A Programmer's Manual

33
:TRIGger Commands

:TRIGger[:EDGE]:LEVel

Command Syntax
:TRIGger[:EDGE]:LEVel <level>
<level> ::= <level>[,<source>]
<level> ::= 0.75 x full-scale voltage from center screen in NR3 format
<level> ::= ±(external range setting) in NR3 format
<level> ::= ±8 V for digital channels (MSO models)
<source> ::= {CHANnel<n> | EXTernal} for the DSO models
<source> ::= {CHANnel<n> | DIGital<d> | EXTernal}
<n> ::= 1 to (# analog channels) in NR1 format
<d> ::= 0 to (# digital channels - 1) in NR1 format
The :TRIGger[:EDGE]:LEVel command sets the trigger level voltage for the active
trigger source.
If the optional source is specified and is not the active source, the level on the active source is
NOTE
not affected and the active source is not changed.
Query Syntax
:TRIGger[:EDGE]:LEVel? [<source>]
The :TRIGger[:EDGE]:LEVel? query returns the trigger level of the current trigger
source.
Return Format
<level><NL>
See Also •
•
•
•
•
1166
(see page 1428)
for internal triggers
for external triggers
for the MSO models
"Introduction to :TRIGger Commands"
":TRIGger[:EDGE]:SOURce"
":EXTernal:RANGe" on page 386
":POD<n>:THReshold"
":DIGital<d>:THReshold"
on page 1139
on page 1169
on page 617
on page 357
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
