:MEASure:PLOSs

Command Syntax
:MEASure:PLOSs [<source>]
<source> ::= {CHANnel<n>| FUNCtion<m> | MATH<m> | WMEMory<r>}
<n> ::= 1 to (# analog channels) in NR1 format
<m> ::= 1 to (# math functions) in NR1 format
<r> ::= 1 to (# ref waveforms) in NR1 format
The :MEASure:PLOSs command installs a power loss measurement on screen.
The <source> parameter is typically a math multiply waveform or other waveform
that represents power (voltage * current). This source can also be specified by the
:MEASure:SOURce command.
Power loss is P
Query Syntax
:MEASure:PLOSs? [<source>]
The :MEASure:PLOSs query returns the switching loss in watts.
Return Format
<return_value><NL>
<return_value> ::= the power loss value in NR3 format
See Also •
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
= Vds * Id
n n
":MEASure:SOURce" on page 529
":POWer:SWITch:APPLy"
, where n is each sample.
n
on page 702
