Keysight Technologies InfiniiVision MSO-X 4022A Programmer's Manual page 1285

Waveform Characteristics
Type
ARBitrary Use these commands to set the arbitrary signal
parameters:
•
":WGEN<w>:FREQuency"
•
":WGEN<w>:PERiod"
•
":WGEN<w>:VOLTage"
•
":WGEN<w>:VOLTage:OFFSet"
page 1316
•
":WGEN<w>:VOLTage:HIGH"
•
":WGEN<w>:VOLTage:LOW"
1
When the output load is 50 Ω, these values are halved.
2
The minimum amplitude is limited to 40 mVpp if the offset is greater than 500 mV or less than -500 mV. Likewise, the offset
is limited to +/-500 mV if the amplitude is less than 40 mVpp.
Query Syntax
:WGEN<w>:FUNCtion?
The :WGEN<w>:FUNCtion? query returns the currently selected signal type.
Return Format
<signal><NL>
<signal> ::= {SIN | SQU | RAMP | PULS | DC | NOIS | SINC | EXPR | EXPF
See Also •
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
on page 1281
on page 1306
on page 1313
on page 1314
on page 1315
| CARD | GAUS | ARB}
"Introduction to :WGEN<w> Commands"
":WGEN<w>:MODulation:NOISe"
Frequency
Range
100 mHz to
12 MHz
on
on page 1272
on page 1297
:WGEN<w> Commands
2
Max. Offset
2 1
Amplitude (High-Z)
1
(High-Z)
20 mVpp to ±5.00 V
10 Vpp
35
