:POWer:SIGNals:OVERshoot

Command Syntax
:POWer:SIGNals:OVERshoot <percent>
<percent> ::= percent of overshoot value in NR1 format
The :POWer:SIGNals:OVERshoot command specifies the percent of overshoot of
the output voltage. This value is used to determine the settling band value for the
transient response and to adjust the vertical scale of the oscilloscope.
Query Syntax
:POWer:SIGNals:OVERshoot?
The :POWer:SIGNals:OVERshoot query returns the overshoot percent setting.
Return Format
<percent><NL>
<percent> ::= percent of overshoot value in NR1 format
See Also •
•
•
•
•
•
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
":POWer:TRANsient:APPLy"
":POWer:SIGNals:AUTosetup"
":POWer:SIGNals:DURation:TRANsient"
":POWer:SIGNals:IEXPected"
":POWer:SIGNals:VSTeady:TRANsient"
":POWer:SIGNals:SOURce:CURRent<i>"
":POWer:SIGNals:SOURce:VOLTage<i>"
on page 708
on page 681
on page 689
on page 690
on page 697
on page 698
on page 699
