:WGEN<w> Commands
:WGEN<w>:FUNCtion
Command Syntax
:WGEN<w>:FUNCtion <signal>
<w> ::= 1 or 2 in NR1 format
<signal> ::= {SINusoid | SQUare | RAMP | PULSe | DC | NOISe | SINC
The :WGEN<w>:FUNCtion command selects the type of waveform:
Waveform Characteristics
Type
SINusoid Use these commands to set the sine signal
parameters:
•
":WGEN<w>:FREQuency"
•
":WGEN<w>:PERiod"
•
":WGEN<w>:VOLTage"
•
":WGEN<w>:VOLTage:OFFSet"
page 1316
•
":WGEN<w>:VOLTage:HIGH"
•
":WGEN<w>:VOLTage:LOW"
SQUare Use these commands to set the square wave signal
parameters:
•
":WGEN<w>:FREQuency"
•
":WGEN<w>:PERiod"
•
":WGEN<w>:VOLTage"
•
":WGEN<w>:VOLTage:OFFSet"
page 1316
•
":WGEN<w>:VOLTage:HIGH"
•
":WGEN<w>:VOLTage:LOW"
•
":WGEN<w>:FUNCtion:SQUare:DCYCle"
on page 1288
The duty cycle can be adjusted from 20% to 80%.
1282
(see page 1428)
| EXPRise | EXPFall | CARDiac | GAUSsian | ARBitrary}
on page 1281
on page 1306
on page 1313
on
on page 1314
on page 1315
on page 1281
on page 1306
on page 1313
on
on page 1314
on page 1315
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
Frequency Max.
Range Amplitude
1
(High-Z)
100 mHz to 20 mVpp to
20 MHz 10 Vpp
100 mHz to 20 mVpp to
10 MHz 10 Vpp
2
Offset
2 1
(High-Z)
±4.00 V
±5.00 V
