:SBUS<n> Commands
:SBUS<n>:UART:TRIGger:TYPE
Command Syntax
:SBUS<n>:UART:TRIGger:TYPE <value>
<value> ::= {RSTArt | RSTOp | RDATa | RD1 | RD0 | RDX | PARityerror
The :SBUS<n>:UART:TRIGger:TYPE command selects the UART trigger type.
When one of the RD or TD types is selected, the :SBUS<n>:UART:TRIGger:DATA
and :SBUS<n>:UART:TRIGger:QUALifier commands are used to specify the data
value and comparison operator.
The RD1, RD0, RDX, TD1, TD0, and TDX types (for triggering on data and alert bit
values) are only valid when a 9-bit width has been selected.
Query Syntax
:SBUS<n>:UART:TRIGger:TYPE?
The :SBUS<n>:UART:TRIGger:TYPE? query returns the current UART trigger data
value.
Return Format
<value><NL>
<value> ::= {RSTA | RSTO | RDAT | RD1 | RD0 | RDX | PAR | TSTA |
See Also •
•
•
•
•
966
(see page 1428)
| TSTArt | TSTOp | TDATa | TD1 | TD0 | TDX}
TSTO | TDAT | TD1 | TD0 | TDX}
"Introduction to :TRIGger Commands"
":TRIGger:MODE" on page 1148
":SBUS<n>:UART:TRIGger:DATA"
":SBUS<n>:UART:TRIGger:QUALifier"
":SBUS<n>:UART:WIDTh"
on page 1139
on page 963
on page 965
on page 967
