:MEASure Power Commands

:MEASure:VCESat

(see page 1428)
Command Syntax
:MEASure:VCESat [<source>]
<source> ::= {CHANnel<n>| FUNCtion<m> | MATH<m> | WMEMory<r>}
<n> ::= 1 to (# analog channels) in NR1 format
<m> ::= 1 to (# math functions) in NR1 format
<r> ::= 1 to (# ref waveforms) in NR1 format
The :MEASure:VCESat command installs a power Vce(sat) measurement on
screen.
Vce(sat) is the saturation voltage between the collector and emitter of a BJT. The
Vce(sat) characteristic is also published in the switching device data sheet.
Query Syntax
:MEASure:VCESat? [<source>]
The :MEASure:VCESat? query returns the measured Vce(sat) value.
Return Format
<return_value><NL>
<return_value> ::= the VCE(sat) value in NR3 format
See Also • ":MEASure:RDSon" on page 572
