:MEASure:XMIN

Command Syntax
:MEASure:XMIN [<source>]
<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | WMEMory<r>}
<n> ::= 1-2 or 1-4 (# of analog channels) in NR1 format
<m> ::= 1 to (# math functions) in NR1 format
<r> ::= 1 to (# ref waveforms) in NR1 format
The :MEASure:XMIN command installs a screen measurement and starts an
X-at-Min-Y measurement on the selected window. If the optional source
parameter is specified, the current source is modified.
:MEASure:XMIN is an alias for :MEASure:TMIN.
NOTE
Query Syntax
:MEASure:XMIN? [<source>]
The :MEASure:XMIN? query measures and returns the horizontal axis value at
which the minimum vertical value occurs. If the optional source is specified, the
current source is modified. If all channels are off, the query returns 9.9E+37.
Return Format
<value><NL>
<value> ::= horizontal value of the minimum in NR3 format
See Also •
•
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
"Introduction to :MEASure Commands"
":MEASure:XMAX" on page 552
":MEASure:TMIN" on page 1359
:MEASure Commands
on page 488
