:POWer:CLResponse:FREQuency:MODE

Command Syntax
:POWer:CLResponse:FREQuency:MODE <mode>
<mode> ::= {SWEep | SINGle}
The :POWer:CLResponse:FREQuency:MODE command specifies whether the
analysis should be performed by sweeping through a range of frequencies
(SWEep) or at a single frequency (SINGle).
The SINGle mode is useful for evaluating amplitudes at a single frequency, for
example, near the expected 0 dB cross-over frequency. After running the test at a
single frequency, you can manually adjust (increase) the waveform generator's
amplitude until you begin to observe distortion in the waveforms on the
oscilloscope's display. You can then use that amplitude at all frequencies in
SWEep mode, or you can evaluate amplitudes at other frequencies in order to
determine an optimized amplitude profile (see
:POWer:CLResponse:WGEN:VOLTage:PROFile).
Query Syntax
:POWer:CLResponse:FREQuency:MODE?
The :POWer:CLResponse:FREQuency:MODE? query returns the frequency mode
setting.
Return Format
<mode><NL>
<mode> ::= {SWE | SING}
See Also •
•
•
•
•
•
•
•
•
•
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
":POWer:CLResponse"
":POWer:CLResponse:APPLy"
":POWer:CLResponse:DATA"
":POWer:CLResponse:FREQuency:STARt"
":POWer:CLResponse:FREQuency:STOP"
":POWer:CLResponse:PPDecade"
":POWer:CLResponse:SOURce:INPut"
":POWer:CLResponse:SOURce:OUTPut"
":POWer:CLResponse:WGEN:LOAD"
":POWer:CLResponse:WGEN:VOLTage"
":POWer:CLResponse:WGEN:VOLTage:PROFile"
on page 626
on page 627
on page 628
on page 630
on page 631
on page 632
on page 633
on page 634
on page 635
on page 636
:POWer Commands
on page 637
