:SBUS<n>:SENT Commands
These commands are valid when the automotive SENT serial decode and triggering option has
NOTE
been licensed.
Table 121 :SBUS<n>:SENT Commands Summary
Command
:SBUS<n>:SENT:CLOCk
<period> (see
page 900)
:SBUS<n>:SENT:CRC
<format> (see
page 901)
:SBUS<n>:SENT:DISPlay
page 902)
<base> (see
:SBUS<n>:SENT:FORMat
<decode> (see
page 904)
:SBUS<n>:SENT:IDLE
page
<state> (see
:SBUS<n>:SENT:LENGth
<#_nibbles> (see
page 907)
:SBUS<n>:SENT:PPULse
{{0 | OFF} | {1 |
page 908)
ON}} (see
:SBUS<n>:SENT:SIGNal<
s>:DISPlay {{0 | OFF}
| {1 | ON}} (see
page 909)
:SBUS<n>:SENT:SIGNal<
s>:LENGth <length>
page 910)
(see
:SBUS<n>:SENT:SIGNal<
s>:MULTiplier
<multiplier> (see
page 912)
:SBUS<n>:SENT:SIGNal<
s>:OFFSet <offset>
page 913)
(see
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
Query
:SBUS<n>:SENT:CLOCk?
page 900)
(see
:SBUS<n>:SENT:CRC?
page 901)
(see
:SBUS<n>:SENT:DISPlay
page 902)
? (see
:SBUS<n>:SENT:FORMat?
page 904)
(see
:SBUS<n>:SENT:IDLE?
906) page 906)
(see
:SBUS<n>:SENT:LENGth?
page 907)
(see
:SBUS<n>:SENT:PPULse?
page 908)
(see
:SBUS<n>:SENT:SIGNal<
s>:DISPlay? (see
page 909)
:SBUS<n>:SENT:SIGNal<
s>:LENGth? (see
page 910)
:SBUS<n>:SENT:SIGNal<
s>:MULTiplier? (see
page 912)
:SBUS<n>:SENT:SIGNal<
s>:OFFSet? (see
page 913)
:SBUS<n> Commands
Options and Query Returns
<period> ::= the nominal clock
period (tick), from 1 us to 300
us, in NR3 format.
<format> ::= {LEGacy |
RECommended}
<base> ::= {HEX | DECimal |
SYMBolic}
<decode> ::= {NIBBles | FSIGnal |
FSSerial | FESerial | SSERial |
ESERial}
<state> ::= {LOW | HIGH}
<#_nibbles> ::= from 1-6, in NR1
format.
{0 | 1}
<s> ::= 1-6, in NR1 format.
{0 | 1}
<s> ::= 1-6, in NR1 format.
<length> ::= from 1-24, in NR1
format.
<s> ::= 1-6, in NR1 format.
<multiplier> ::= from 1-24, in
NR3 format.
<s> ::= 1-6, in NR1 format.
<offset> ::= from 1-24, in NR3
format.
