Keysight Technologies InfiniiVision MSO-X 4022A Programmer's Manual page 498

22
:MEASure Commands
<slope> ::= {+ | -}
<occurrence> ::= integer
This command defines the behavior of the :MEASure:DELay? query by specifying
the start and stop edge to be used. <edge_spec1> specifies the slope and edge
number on source1. <edge_spec2> specifies the slope and edge number on
source2. The measurement is taken as:
delay = t(<edge_spec2>) - t(<edge_spec1>)
The :MEASure:DELay command and the front-panel delay measurement use an auto-edge
NOTE
selection method to determine the actual edge used for the measurement. The
:MEASure:DEFine command has no effect on these delay measurements. The edges specified
by the :MEASure:DEFine command only define the edges used by the :MEASure:DELay? query.
:MEASure:DEFine
:MEASure:DEFine THResholds,<threshold spec>[,<source>]
THResholds
<threshold spec> ::= {STANdard}
Command Syntax
<threshold mode> ::= {PERCent | ABSolute}
for <threshold mode> = PERCent:
<upper>, <middle>, <lower> ::= A number specifying the upper, middle,
for <threshold mode> = ABSolute:
<upper>, <middle>, <lower> ::= A number specifying the upper, middle,
• STANdard threshold specification sets the lower, middle, and upper
• Threshold mode PERCent sets the measurement thresholds to any user-defined
• Threshold mode ABSolute sets the measurement thresholds to absolute values.
Query Syntax
:MEASure:DEFine? <meas_spec>[,<source>]
<meas_spec> ::= {DELay | THResholds}
The :MEASure:DEFine? query returns the current edge specification for the delay
measurements setup or the current specification for the thresholds setup.
498
| {<threshold mode>,<upper>,<middle>,<lower>}
measurement thresholds to 10%, 50%, and 90% values between Vbase and
Vtop.
percentages between 5% and 95% of values between Vbase and Vtop.
ABSolute thresholds are dependent on channel scaling (:CHANnel<n>:RANGe
or ":CHANnel<n>:SCALe"
(:CHANnel<n>:PROBe), and probe units (:CHANnel<n>:UNITs). Always set
these values first before setting ABSolute thresholds.
and lower threshold percentage values
between Vbase and Vtop in NR3 format.
and lower threshold absolute values in
NR3 format.
on page 321:CHANnel<n>:SCALe), probe attenuation
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
