Marker:x2Y2Source - Keysight Technologies InfiniiVision MSO-X 4022A Programmer's Manual

:MARKer:X2Y2source

Command Syntax
:MARKer:X2Y2source <source>
<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | WMEMory<r>}
<n> ::= 1 to (# analog channels) in NR1 format
<m> ::= 1 to (# math functions) in NR1 format
<r> ::= 1 to (# ref waveforms) in NR1 format
The :MARKer:X2Y2source command sets the source for the cursors. The channel
you specify must be enabled for cursors to be displayed. If the channel or function
is not on, an error message is issued.
If the marker mode is not currently WAVeform (see
page 455):
• Sending a :MARKer:X2Y2source command will put the cursors in the MANual
• Setting the source for one pair of markers (for example, X2Y2) sets the source
If the marker mode is currently WAVeform, the X2Y2 source can be set separate
from the X1Y1 source.
If :MARKer:MODE is set to OFF or MANual, setting :MEASure:SOURce to
CHANnel<n>, FUNCtion, MATH, or WMEMory<r> will also set
:MARKer:X1Y1source and :MARKer:X2Y2source to this value.
MATH is an alias for FUNCtion. The query will return FUNC if the source is FUNCtion or MATH.
NOTE
Query Syntax
:MARKer:X2Y2source?
The :MARKer:X2Y2source? query returns the current source for the cursors. If all
channels are off or if :MARKer:MODE is set to OFF, the query returns NONE.
Return Format
<source><NL>
<source> ::= {CHAN<n> | FUNC | WMEM<r> | NONE}
See Also •
•
•
•
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1428)
mode.
for the other (for example, X1Y1).
"Introduction to :MARKer Commands"
":MARKer:MODE" on page 455
":MARKer:X1Y1source"
":MEASure:SOURce" on page 529
on page 453
on page 458
:MARKer Commands
":MARKer:MODE" on
21
461
