:TRIGger Commands

:TRIGger:OR

Command Syntax
:TRIGger:OR <string>
<string> ::= "nn...n" where n ::= {R | F | E | X}
R = rising edge, F = falling edge, E = either edge, X = don't care.
The :TRIGger:OR command specifies the edges to include in the OR'ed edge
trigger.
In the <string> parameter, each bit corresponds to a channel as described in the
following table:
Oscilloscope Models
4 analog + 16 d igital channels (mixed-signal)
2 analog + 16 d igital channels (mixed-signal)
4 analog channels only
2 analog channels only
Query Syntax
:TRIGger:OR?
The :TRIGger:OR? query returns the current OR'ed edge trigger string.
Return Format
<string><NL>
See Also •
•
1190
(see page 1428)
"Introduction to :TRIGger Commands"
":TRIGger:MODE" on page 1148
Value and Mask Bit Assignments
Bits 0 through 15 - digital channels 0 through
15. Bits 16 through 19 - analog channels 4
through 1.
Bits 0 through 15 - digital channels 0 through
15. Bits 16 and 17 - analog channels 2 and 1.
Bits 0 through 3 - analog channels 4 through 1.
Bits 0 and 1 - analog channels 2 and 1.
on page 1139
