26
:POWer Commands

:POWer:PSRR:FREQuency:MODE

Command Syntax
:POWer:PSRR:FREQuency:MODE <mode>
<mode> ::= {SWEep | SINGle}
The :POWer:PSRR:FREQuency:MODE command specifies whether the analysis
should be performed by sweeping through a range of frequencies (SWEep) or at a
single frequency (SINGle).
The SINGle mode is useful for evaluating amplitudes at a single frequency. After
running the test at a single frequency, you can manually adjust (increase) the
waveform generator's amplitude until you begin to observe distortion in the
waveforms on the oscilloscope's display. You can then use that amplitude at all
frequencies in SWEep mode, or you can evaluate amplitudes at other frequencies
in order to determine an optimized amplitude profile (see
:POWer:PSRR:WGEN:VOLTage:PROFile).
Query Syntax
:POWer:CLResponse:FREQuency:MODE?
The :POWer:PSRR:FREQuency:MODE? query returns the frequency mode setting.
Return Format
<mode><NL>
<mode> ::= {SWE | SING}
See Also
672
(see
page
1428)
":POWer:PSRR"
on page 667
":POWer:PSRR:APPLy"
":POWer:PSRR:DATA"
":POWer:PSRR:FREQuency:MAXimum"
":POWer:PSRR:FREQuency:MINimum"
":POWer:PSRR:PPDecade"
":POWer:PSRR:SOURce:INPut"
":POWer:PSRR:SOURce:OUTPut"
":POWer:PSRR:WGEN:LOAD"
":POWer:PSRR:WGEN:VOLTage"
":POWer:PSRR:WGEN:VOLTage:PROFile"
on page 668
on page 669
on page 670
on page 671
on page 673
on page 674
on page 675
on page 676
on page 677
on page 678
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
