E5 User Manual

Unit's place: baud rate
0: 4800bps
1: 9600bps
2: 19200bps
3: 38400bps
4: 57600bps
5: 115200bps

Decade: data format
0: 1-8-2-N format, RTU
1: 1-8-1-E format, RTU
2: 1-8-1-O format, RTU
3: 1-7-2-N format, ASCII
4: 1-7-1-E format, ASCII
5: 1-7-1-O format, ASCII

Hundreds place: connection type
0: Direct cable connection (232/485)
1: Reserved
RS-485 communication
P60.02
Sets this drive address. 0 is broadcast address, while available addresses are 1~247.
P60.03 Time out detection
This parameter sets communication error detection time. When it's set to 0, no communication
error will be reported.
P60.04 Communication time delay
Sets response time delay of this drive to the master.
P60.05 Master/Slave option
0: PC controls the drive
PC as master controls the drive. This supports all communication protocols.
1: As master
This drive as master sends current running frequency data through RS-485 port. Data cannot
be received but sent, and the sending data is only running frequency.
2: As slave
Put the received data into P10.02 (digital setting of master frequency) or P50.01 (PID digital
setting) through communication. P10.02/P50.01 is selected by parameter P60.06. Other
address
Chapter 5 Specification of Parameters
Range: 0~247
Range: 0.0s~1000.0s
Range: 0ms~1000ms
Range: 0~2
- 165 -
Factory default: 5
Factory default:
0.0s
Factory default:
0ms
Factory default: 0
