Parameter Descriptions
17-52 Input Frequency
Range: Function:
10.0 kHz [2.0 - 15.0 kHz] Set the input frequency to the resolver.
*
The value is stated in the data sheet for
resolvers.
17-53 Transformation Ratio
Range: Function:
0.5 [0.1 - 1.1 ] Set the transformation ratio for the resolver.
*
The transformation ration is:
V Out
T ratio =
V In
The value is stated in the data sheet for
resolvers.
17-56 Encoder Sim. Resolution
Set the resolution and activate the encoder emulation function
(generation of encoder signals from the measured position from a
resolver). Needed when necessary to transfer the speed or position
information from one drive to another. To disable the function,
select [0].
Option:
[0] Disabled
*
[1] 512
[2] 1024
[3] 2048
[4] 4096
17-59 Resolver Interface
Activate the MCB 103 resolver option when the resolver
parameters are selected.
To avoid damage to resolvers 17-50 Poles – 17-53 Transformation
Ratio must be adjusted before activating this parameter.
Option:
[0] Disabled
*
[1] Enabled
3.18.4 17-6* Monitoring and Application
This parameter group is for selecting additional functions
when MCB 102 Encoder option or MCB 103 Resolver option
is fitted into option slot B as speed feedback.
Monitoring and Application parameters cannot be adjusted
while the motor is running.
17-60 Feedback Direction
Change the detected encoder rotation direction without changing
the wiring to the encoder.
This parameter cannot be adjusted while the motor is running.
Option:
[0] Clockwise
*
[1] Counter clockwise
FC 300 Programming Guide
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
Function:
Function:
Function:
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
17-61 Feedback Signal Monitoring
Select which reaction the frequency converter should take in case a
faulty encoder signal is detected.
The encoder function in 17-61 Feedback Signal Monitoring is an
electrical check of the hardware circuit in the encoder system.
Option:
Disabled
Warning
*
Trip
Jog
Freeze Output
Max Speed
Switch to Open Loop
Select Setup 1
Select Setup 2
Select Setup 3
Select Setup 4
stop & trip
