Parameter Descriptions
0-13 Readout: Linked Set-ups
Array [5]
Range: Function:
0 [0 - View a list of all the set-ups linked by means of 0-12 This
255 ] Set-up Linked to. The parameter has one index for each
*
3 3
parameter set-up. The parameter value displayed for
each index represents which setups are linked to that
parameter setup.
Index
0
1
2
3
4
Table 3.2 Example: Set-up 1 and Set-up 2 are linked
0-14 Readout: Edit Set-ups / Channel
Range:
0 [-2147483648 -
*
2147483647 ]
26
FC 300 Programming Guide
LCP value
{0}
{1,2}
{1,2}
{3}
{4}
Function:
View the setting of 0-11 Edit Set-up for each
of the four different communication
channels. When the number is displayed in
hex, as it is in the LCP, each number
represents one channel.
Numbers 1-4 represent a set-up number; 'F'
means factory setting; and 'A' means active
set-up. The channels are, from right to left:
LCP, FC-bus, USB, HPFB1-5.
Example: The number AAAAAA21h means
that the FC bus selected Set-up 2 in 0-11 Edit
Set-up, the LCP selected Set-up 1 and all
others used the active set-up.
MG.33.MB.02 - VLT
3.2.3 0-2* LCP Display
Define the variables displayed in the Graphical Local Control
Panel.
NOTE
Please refer to 0-37 Display Text 1, 0-38 Display Text 2 and
0-39 Display Text 3 for information on how to write display
texts.
0-20 Display Line 1.1 Small
Option:
[0] None
*
[9] Performance Monitor
[37] Display Text 1
[38] Display Text 2
[39] Display Text 3
[748] PCD Feed Forward
[953] Profibus Warning
Word
[1005] Readout Transmit
Error Counter
[1006] Readout Receive Error
Counter
[1007] Readout Bus Off
Counter
[1013] Warning Parameter
[1230] Warning Parameter
[1472] Legacy Alarm Word
[1473] Legacy Warning Word
[1474] Leg. Ext. Status Word
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value [%] Actual value as a percentage.
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
®
is a registered Danfoss trademark
Function:
Select a variable for display in line
1, left position.
No display value selected.
Present control word
Total reference (sum of digital/
analog/preset/bus/freeze ref./
catch up and slow-down) in
selected unit.
Total reference (sum of digital/
analog/preset/bus/freeze ref./
catch up and slow-down) in
percent.
Present status word.
Actual power consumed by the
motor in kW.
Actual power consumed by the
motor in HP.
