How to Programme
Status screen I
This read-out state is standard after start-up or initialization.
Use [INFO] to obtain information about the measurement
links to the displayed operating variables (1.1, 1.2, 1.3, 2 and
3).
See the operating variables shown in the screen below.
Status
799 RPM
1.1
1.2
Auto Remote Ramping
2
3
Status screen II
See the operating variables (1.1, 1.2, 1.3 and 2) shown in the
screen below.
In the example, Speed, Motor current, Motor power and
Frequency are selected as variables in the first and second.
Status
207RPM
1.1
Auto Remote Running
Status screen III
This state displays the event and action of the Smart Logic
Control. For further information, see section Smart Logic
Control.
Status
778 RPM
State: 0 o 0 (o )
When: -
Do: -
Auto Remote Running
FC 300 Programming Guide
1 (1)
7.83 A 36.4 kw
0.000
53.2 %
1.3
1 (1)
5.25A 24.4 kW
6.9
Hz
1.3
1.2
2
1 (1)
0.86 A 4.0 kW
®
MG.33.MB.02 - VLT is a registered Danfoss trademark

2.1.6 Parameter Set-Up

The frequency converter can be used for practically all
assignments, which is why the number of parameters is quite
large. The frequency converter offers a choice between two
programming modes - a Main Menu and a Quick Menu
mode.
The former provides access to all parameters. The latter takes
the user through a few parameters making it possible to start
operating the frequency converter.
Regardless of the mode of programming, you can change a
parameter both in the Main Menu mode and in the Quick
Menu mode.

2.1.7 Quick Menu Key Functions

Pressing [Quick Menus] The list indicates the different areas
contained in the Quick menu.
Select My Personal Menu to display the chosen personal
parameters. These parameters are selected in 0-25 My
Personal Menu. Up to 20 different parameters can be added
in this menu.
40.0%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Select Quick setup to go through a limited amount of
parameters to get the motor running almost optimally. The
default setting for the other parameters considers the
desired control functions and the configuration of signal
inputs/outputs (control terminals).
The selection of parameter is effected by means of the arrow
keys. The parameters in the following table are accessible.
Parameter
0-01 Language
1-20 Motor Power [kW]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
5-12 Terminal 27 Digital Input
1-29 Automatic Motor
Adaptation (AMA)
3-02 Minimum Reference
3-03 Maximum Reference
3-41 Ramp 1 Ramp up Time
3-42 Ramp 1 Ramp Down Time
3-13 Reference Site
4.84 A 1(1)
Setting
[kW]
[V]
[Hz]
[A]
[rpm]
[0] No function*
[1] Enable complete AMA
[rpm]
[rpm]
[sec]
[sec]
15
