Danfoss VLT AutomationDrive FC 300 Programming Manual page 77

Parameter Descriptions
[30] Brake fault
(IGBT)
3 3
[31] Relay 123
[32] Mechanical
brake control
[33] Safe stop
activated (FC
302 only)
[40] Out of ref range Active when the actual speed is outside
[41] Below reference
low
[42] Above
reference high
[43] Extended PID
Limit
[45] Bus Ctrl
[46] Bus Ctrl On at
timeout
[47] Bus Ctrl Off at
timeout
[51] MCO controlled Active when a MCO 302 or MCO 305 is
[55] Pulse output
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
76
FC 300 Programming Guide
Output is Logic '1' when the brake IGBT is
short-circuited. Use this function to protect
the frequency converter if there is a fault
on the brake modules. Use the output/
relay to cut out the main voltage from the
frequency converter.
Relay is activated when Control Word [0] is
selected in parameter group 8-**.
Enables control of an external mechanical
brake, see description in the section
Control of Mechanical Brake, and parameter
group 2-2*
Indicates that the safe stop on terminal 37
has been activated.
settings in 4-52 Warning Speed Low to
4-55 Warning Reference High.
Active when actual speed is below speed
reference setting.
Active when actual speed is above speed
reference setting
Controls output via bus. The state of the
output is set in 5-90 Digital & Relay Bus
Control. The output state is retained in the
event of bus time-out.
Controls output via bus. The state of the
output is set in 5-90 Digital & Relay Bus
Control. In the event of bus time-out the
output state is set high (On).
Controls output via bus. The state of the
output is set in 5-90 Digital & Relay Bus
Control. In the event of bus time-out the
output state is set low (Off).
connected. The output is controlled from
option.
See parameter group 13-1*. If Comparator
0 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See parameter group 13-1*. If Comparator
1 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See parameter group 13-1*. If Comparator
2 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See parameter group 13-1*. If Comparator
3 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See parameter group 13-1*. If Comparator
4 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
MG.33.MB.02 - VLT
[65] Comparator 5
[70] Logic Rule 0
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic Rule 3
[74] Logic Rule 4
[75] Logic Rule 5
[80] SL Digital
Output A
[81] SL Digital
Output B
[82] SL Digital
Output C
[83] SL Digital
Output D
[84] SL Digital
Output E
[85] SL Digital
Output F
®
is a registered Danfoss trademark
See parameter group 13-1*. If Comparator
5 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See parameter group 13-4*. If Logic Rule 0
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See parameter group 13-4*. If Logic Rule 1
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See parameter group 13-4*. If Logic Rule 2
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See parameter group 13-4*. If Logic Rule 3
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See parameter group 13-4*. If Logic Rule 4
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See parameter group 13-4*. If Logic Rule 5
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See 13-52 SL Controller Action. The output
will go high whenever the Smart Logic
Action [38] Set dig. out. A high is executed.
The output will go low whenever the
Smart Logic Action [32] Set dig. out. A low
is executed.
See 13-52 SL Controller Action. The input
will go high whenever the Smart Logic
Action [39] Set dig. out. A high is executed.
The input will go low whenever the Smart
Logic Action [33] Set dig. out. A low is
executed.
See 13-52 SL Controller Action. The input
will go high whenever the Smart Logic
Action [40] Set dig. out. A high is executed.
The input will go low whenever the Smart
Logic Action [34] Set dig. out. A low is
executed.
See 13-52 SL Controller Action. The input
will go high whenever the Smart Logic
Action [41] Set dig. out. A high is executed.
The input will go low whenever the Smart
Logic Action [35] Set dig. out. A low is
executed.
See 13-52 SL Controller Action. The input
will go high whenever the Smart Logic
Action [42] Set dig. out. A high is executed.
The input will go low whenever the Smart
Logic Action [36] Set dig. out. A low is
executed.
See 13-52 SL Controller Action. The input
will go high whenever the Smart Logic
Action [43] Set dig. out. A high is executed.
The input will go low whenever the Smart
Logic Action [37] Set dig. out. A low is
executed.
