Parameter Lists

4 Parameter Lists
FC Series
All = valid for FC 301 and FC 302 series
01 = valid for FC 301 only
02 = valid for FC 302 only
Changes during operation
"TRUE" means that the parameter can be changed while the
frequency converter is in operation and "FALSE" means that
the frequency converter must be stopped before a change
can be made.
4-Set-up
'All set-ups': the parameter can be set individually in each of
the four set-ups, i. e. one single parameter can have four
different data values.
'1 set-up': data value will be the same in all set-ups.
Data Description
type
2 Integer 8
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Visible String
33 Normalized value 2 bytes
35 Bit sequence of 16 boolean variables
54 Time difference w/o date
4.1.1 Conversion
The various attributes of each parameter are displayed in the
section Factory Settings. Parameter values are transferred as
whole numbers only. Conversion factors are therefore used
to transfer decimals.
4-12 Motor Speed Low Limit [Hz] has a conversion factor of
0.1.
To preset the minimum frequency to 10 Hz, transfer the
value 100. A conversion factor of 0.1 means that the value
transferred is multiplied by 0.1. The value 100 is thus
perceived as 10.0.
Examples:
0s --> conversion index 0
0.00s --> conversion index -2
0ms --> conversion index -3
0.00ms --> conversion index -5
FC 300 Programming Guide
Conversion table
Conversion index
100
75
74
67
6
5
4
3
2
1
0
-1
-2
-3
-4
Type
-5
-6
Int8
-7
Int16
Int32
Uint8
Uint16
Uint32
VisStr
N2
V2
TimD
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
Conversion factor
1000000
100000
10000
1000
100
10
1
0.1
0.01
0.001
0.0001
0.00001
0.000001
0.0000001
165
4 4
