Parameter Descriptions
16-37 Inv. Max. Current
Range:
Application
dependent
*
3 3
16-38 SL Controller State
Range:
0 [0 - 100 ] View the state of the event under execution by the
*
16-39 Control Card Temp.
Range:
0 C [0 - 100 C] View the temperature on the control card,
*
16-40 Logging Buffer Full
Option: Function:
View whether the logging buffer is full (see parameter
group 15-1*). The logging buffer will never be full when
15-13 Logging Mode is set to Log always [0].
[0] No
*
[1] Yes
16-49 Current Fault Source
Range:
0 [0 - 8 ] Value indicates source of current faults including
*
short circuit, over current, and phase imbalance
(from left):
1-4 Inverter
5-8 Rectifier
0 No fault recorded
3.17.4 16-5* Ref. & Feedb.
16-50 External Reference
Range:
0.0 [-200.0 - 200.0 ] View the total reference, the sum of digital,
*
16-51 Pulse Reference
Range:
0.0 [-200.0 -
*
200.0 ]
152
Function:
[0.01 - View the inverter maximum
10000.00 A] current, which should match the
nameplate data on the
connected motor. The data are
used for calculation of torque,
motor protection, etc.
Function:
SL controller.
Function:
stated in °C
Function:
Function:
analog, preset, bus and freeze references,
plus catch-up and slow-down.
Function:
View the reference value from programmed
digital input(s). The read-out can also reflect
the impulses from an incremental encoder.
MG.33.MB.02 - VLT
FC 300 Programming Guide
16-52 Feedback [Unit]
Range:
0.000 Reference-
FeedbackUnit
16-53 Digi Pot Reference
Range:
0.00
*
16-57 Feedback [RPM]
Range:
0 RPM
*
®
is a registered Danfoss trademark
[-999999.999 -
999999.999
*
ReferenceFeed-
backUnit]
Function:
[-200.00 - 200.00 ] View the contribution of the Digital
Potentiometer to the actual reference.
Function:
[-30000 - Read-out parameter where the actual
30000 RPM] motor RPM from the feed-back source can
be read in both closed loop and open
loop. The feed-back source is selected by
7-00 Speed PID Feedback Source.
Function:
View the feedback unit
resulting from the
selection of unit and
scaling in 3-00 Reference
Range, 3-01 Reference/
Feedback Unit,
3-02 Minimum Reference
and 3-03 Maximum
Reference.
