Parameter Descriptions
5-19 Terminal 37 Safe Stop
Option:
[1] Safe Stop
*
Alarm
3 3
[3] Safe Stop
Warning
[4] PTC 1 Alarm Coasts frequency converter when safe stop is
[5] PTC 1
Warning
[6] PTC 1 &
Relay A
[7] PTC 1 &
Relay W
[8] PTC 1 &
Relay A/W
[9] PTC 1 &
Relay W/A
Choises 4 - 9 are only available when the MCB 112 PTC
Thermistor Card is connected.
NOTE
When Auto Reset/Warning is selected the frequency
converter opens up for automatic restart.
74
FC 300 Programming Guide
Function:
Coasts frequency converter when safe stop is
activated. Manual reset from LCP, digital input
or fieldbus.
Coasts frequency converter when safe stop is
activated (T-37 off). When safe stop circuit is
reestablished, the frequency converter will
continue without manual reset.
activated. Manual reset from LCP, digital input
or fieldbus. Choice 4 is only available when the
MCB 112 PTC Thermistor Card is connected.
Coasts frequency converter when safe stop is
activated (T-37 off). When safe stop circuit is
reestablished, the frequency converter will
continue without manual reset, unless a Digital
Input set to PTC Card 1 [80] is still enabled.
Choice 5 is only available when the MCB 112
PTC Thermistor Card is connected.
This choice is used when the PTC option is
gated together with a Stop button through a
Safety relay to T-37. Coasts frequency converter
when safe stop is activated. Manual reset from
LCP, digital input or fieldbus. Choice 6 is only
available when the MCB 112 PTC Thermistor
Card is connected.
This choice is used when the PTC option is
gated together with a Stop button through a
Safety relay to T-37. Coasts frequency converter
when safe stop is activated (T-37 off). When
safe stop circuit is reestablished, the frequency
converter will continue without manual reset,
unless a Digital Input set to PTC Card 1 [80] is
(still) enabled. Choice 7 is only available when
the MCB 112 PTC Thermistor Card is connected.
This choice makes it possible to use a
combination of Alarm and Warning. Choice 8 is
only available when the MCB 112 PTC
Thermistor Card is connected.
This choice makes it possible to use a
combination of Alarm and Warning. Choice 9 is
only available when the MCB 112 PTC
Thermistor Card is connected.
MG.33.MB.02 - VLT
Overview of functions, alarms and warnings
Function No.
No Function [0]
Safe Stop Alarm [1]*
Safe Stop Warning [3]
PTC 1 Alarm [4]
PTC 1 Warning [5]
PTC 1 & Relay A [6]
PTC 1 & Relay W [7]
PTC 1 & Relay A/W [8]
PTC 1 & Relay W/A [9]
W means warning and A means alarm. For further
information, see Alarms and Warnings in section Trouble-
shooting in the Design Guide or the Operating Instructions
A dangerous failure related to Safe Stop will give Alarm:
Dangerous Failure [A72].
Please refer to the section Description of Alarm Word, Warning
Word and extended Status Word in the chapter Trouble-
shooting.
5-20 Terminal X46/1 Digital Input
Option:
[0] No operation This parameter is active when option module
*
MCB 113 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
5-21 Terminal X46/3 Digital Input
Option:
[0] No operation This parameter is active when option
*
moduleMCB 113 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
5-22 Terminal X46/5 Digital Input
Option:
[0] No operation This parameter is active when option
*
moduleMCB 113 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
5-23 Terminal X46/7 Digital Input
Option:
[0] No operation This parameter is active when option
*
moduleMCB 113 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
®
