Parameter Descriptions
13-52 SL Controller Action
Array [20]
Option: Function:
[15] Select preset Select preset reference 5 [15] – selects preset
ref 5 reference 5.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[16] Select preset Select preset reference 6 [16] – selects preset
ref 6 reference 6.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[17] Select preset Select preset reference 7 [17] - selects preset
ref 7 reference 7.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[18] Select ramp 1 Select ramp 1 [18] - selects ramp 1.
[19] Select ramp 2 Select ramp 2 [19] - selects ramp 2.
[20] Select ramp 3 Select ramp 3 [20] - selects ramp 3.
[21] Select ramp 4 Select ramp 4 [21] - selects ramp 4.
[22] Run Run [22] - issues a start command to the
frequency converter.
[23] Run reverse Run reverse [23] - issues a start reverse
command to the frequency converter.
[24] Stop Stop [24] - issues a stop command to the
frequency converter.
[25] Qstop Qstop [25] - issues a quick stop command to
the frequency converter.
[26] Dcstop Dcstop [26] - issues a DC stop command to
the frequency converter.
[27] Coast Coast [27] - the frequency converter coasts
immediately. All stop commands including
the coast command stop the SLC.
[28] Freeze output Freeze output [28] - freezes the output
frequency of the frequency converter.
[29] Start timer 0 Start timer 0 [29] - starts timer 0, see 13-20 SL
Controller Timer for further description.
[30] Start timer 1 Start timer 1 [30] - starts timer 1, see 13-20 SL
Controller Timer for further description.
[31] Start timer 2 Start timer 2 [31] - starts timer 2, see 13-20 SL
Controller Timer for further description.
[32] Set digital out Set digital output A low [32] - any output with
A low SL output A will be low.
FC 300 Programming Guide
[33] Set digital out
[34] Set digital out
[35] Set digital out
[36] Set digital out
[37] Set digital out
[38] Set digital out
[39] Set digital out
[40] Set digital out
[41] Set digital out
[42] Set digital out
[43] Set digital out
[60] Reset Counter
[61] Reset Counter
[70] Start timer 3
[71] Start timer 4
[72] Start timer 5
[73] Start timer 6
[74] Start timer 7
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
13-52 SL Controller Action
Array [20]
Option: Function:
Set digital output B low [33] - any output with
B low SL output B will be low.
Set digital output C low [34] - any output with
C low SL output Cwill be low.
Set digital output D low [35] - any output with
D low SL output D will be low.
Set digital output E low [36] - any output with
E low SL output E will be low.
Set digital output F low [37] - any output with
F low SL output F will be low.
Set digital output A high [38] - any output
A high with SL output A will be high.
Set digital output B high [39] - any output
B high with SL output B will be high.
Set digital output C high [40] - any output
C high with SL output C will be high.
Set digital output D high [41] - any output
D high with SL output D will be high.
Set digital output E high [42] - any output
E high with SL output E will be high.
Set digital output F high [43] - any output
F high with SL output Fwill be high.
Reset Counter A [60] - resets Counter A to
A zero.
Reset Counter B [61] - resets Counter B to
B zero.
Start Timer 3 [70] - Start Timer 3, see 13-20 SL
Controller Timer for further description.
Start Timer 4 [71] - Start Timer 4, see 13-20 SL
Controller Timer for further description.
Start Timer 5 [72] - Start Timer 5, see 13-20 SL
Controller Timer for further description.
Start Timer 6 [73] - Start Timer 6, see 13-20 SL
Controller Timer for further description.
Start Timer 7 [74] - Start Timer 7, see
p13-20 SL Controller Timer for further
description.
