Parameter Descriptions
13-42 Logic Rule Boolean 2
Array [6]
Option:
[85] Digital input x46/13
[90] ATEX ETR cur. warning
3 3
[91] ATEX ETR cur. alarm
[92] ATEX ETR freq. warning Selectable if1-90 Motor Thermal
[93] ATEX ETR freq. alarm
13-43 Logic Rule Operator 2
Array [6]
Option:
[0] DISABLED
*
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
134
FC 300 Programming Guide
Function:
Selectable if 1-90 Motor Thermal
Protection is set to [20] or [21]. If the
alarm 164 ATEX ETR cur.lim.alarm is
active, the output will be 1.
Selectable if 1-90 Motor Thermal
Protection is set to [20] or [21]. If the
alarm 166 ATEX ETR freq.lim.alarm is
active, the output will be 1.
Protection is set to [20] or [21] ]. If
the alarm 163 ATEX ETR
cur.lim.warning is active, the output
will be 1.
Selectable if 1-90 Motor Thermal
Protection is set to [20] or [21]. If the
warning 165 ATEX ETR
freq.lim.warning is active, the
output will be 1.
Function:
Select the second logical operator to be used
on the boolean input calculated in
13-40 Logic Rule Boolean 1, 13-41 Logic Rule
Operator 1, and 13-42 Logic Rule Boolean 2,
and the boolean input coming from
13-42 Logic Rule Boolean 2.
[13-44] signifies the boolean input of
13-44 Logic Rule Boolean 3.
[13-40/13-42] signifies the boolean input
calculated in 13-40 Logic Rule Boolean 1,
13-41 Logic Rule Operator 1, and 13-42 Logic
Rule Boolean 2. DISABLED [0] (factory setting).
select this option to ignore 13-44 Logic Rule
Boolean 3.
MG.33.MB.02 - VLT
13-44 Logic Rule Boolean 3
Array [6]
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
®
is a registered Danfoss trademark
Function:
Select the third boolean (TRUE or
FALSE) input for the selected logic
rule. See 13-01 Start Event ([0] - [61])
and 13-02 Stop Event ([70] - [75]) for
further description.
