Parameter Descriptions
13-02 Stop Event
Select the boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option:
3 3
13-03 Reset SLC
Option:
[0] Do not reset SLC Retains programmed settings in all group
*
[1] Reset SLC
3.14.3 13-1* Comparators
Comparators are used for comparing continuous variables
(i.e. output frequency, output current, analog input etc.) to
fixed preset values.
Par. 13-10
Comparator Operand
Par. 13-12
Comparator Value
In addition, there are digital values that will be compared to
fixed time values. See explanation in 13-10 Comparator
Operand. Comparators are evaluated once in each scan
interval. Use the result (TRUE or FALSE) directly. All
parameters in this parameter group are array parameters
with index 0 to 5. Select index 0 to programme Comparator
0, select index 1 to programme Comparator 1, and so on.
13-10 Comparator Operand
Array [6]
Option:
[0] DISABLED
*
[1] Reference
128
FC 300 Programming Guide
Function:
warning 165 ATEX ETR
freq.lim.warning is active, the
output will be 1.
Function:
13 parameters (13-**).
Resets all group 13 parameters (13-**) to
default settings.
Par. 13-11
Comparator Operator
=
TRUE longer than.
. . .
. . .
Function:
Choice [1] to [31] are variables which will
be compared based on their values.
Choice [50] to [186] are digital values
(TRUE/FALSE) where the comparison is
based on the amount of time during
which they are set to TRUE or FALSE,
respectively. See 13-11 Comparator
Operator.
Select the variable to be monitored by
the comparator.
DISABLED [0] The comparator is disabled.
Reference [1] The resulting remote
reference (not local) as a percentage.
MG.33.MB.02 - VLT
13-10 Comparator Operand
Array [6]
Option:
[2] Feedback
[3] Motor speed
[4] Motor current
[5] Motor torque
[6] Motor power
[7] Motor voltage
[8] DC-link voltage
[9] Motor thermal
[10] Drive thermal
[11] Heat sink temp.
[12] Analog input
AI53
[13] Analog input
AI54
[14] Analog input
AIFB10
[15] Analog input
AIS24V
[17] Analog input
AICCT
[18] Pulse input FI29
[19] Pulse input FI33
[20] Alarm number
[21] Warning number
[22] Analog input x30
11
[23] Analog input x30
12
[30] Counter A
[31] Counter B
[50] FALSE
[51] TRUE
[52] Control ready
®
is a registered Danfoss trademark
Function:
Feedback [2] In the unit [RPM] or [Hz]
Motor speed [3] [RPM] or [Hz]
Motor current [4] [A]
Motor torque [5] [Nm]
Motor power [6] [kW] or [hp]
Motor voltage [7] [V]
DC-link voltage [8] [V]
Motor thermal [9] Expressed as a
percentage.
VLT thermal [10] Expressed as a
percentage.
Heat sink temp [11] Expressed as a
percentage.
Analog input AI53 [12] Expressed as a
percentage.
Analog input AI54 [13] Expressed as a
percentage.
Analog input AIFB10 [14] [V]. AIFB10 is
internal 10V supply.
Analog input AIS24V [15] [V] Analog input
AICCT [17] [°]. AIS24V is switch mode
power supply: SMPS 24V.
Analog input AICCT [17] [°]. AICCT is
control card temperature.
Pulse input FI29 [18] Expressed as a
percentage.
Pulse input FI33 [19] Expressed as a
percentage.
Alarm number [20] The error number.
Counter A [30] Number of counts
Counter B [31] Number of counts
False [50] Enters the fixed value of false in
the comparator.
True [51] Enters the fixed value of true in
the comparator.
Control ready [52] The control board
receives supply voltage
