Parameter Descriptions
13-51 SL Controller Event
Array [20]
Option:
[51] Comparator 5
[60] Logic rule 4
3 3
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning
[91] ATEX ETR cur. alarm
[92] ATEX ETR freq. warning Selectable if 1-90 Motor Thermal
[93] ATEX ETR freq. alarm
13-52 SL Controller Action
Array [20]
Option:
[0] DISABLED
*
[1] No action
136
FC 300 Programming Guide
Function:
Selectable if 1-90 Motor Thermal
Protection is set to [20] or [21]. If the
alarm 164 ATEX ETR cur.lim.alarm is
active, the output will be 1.
Selectable if 1-90 Motor Thermal
Protection is set to [20] or [21]. If the
alarm 166 ATEX ETR freq.lim.alarm is
active, the output will be 1.
Protection is set to [20] or [21] ]. If
the alarm 163 ATEX ETR
cur.lim.warning is active, the output
will be 1.
Selectable if 1-90 Motor Thermal
Protection is set to [20] or [21]. If the
warning 165 ATEX ETR
freq.lim.warning is active, the
output will be 1.
Function:
Select the action corresponding to the SLC
event. Actions are executed when the
corresponding event (defined in 13-51 SL
Controller Event) is evaluated as true. The
following actions are available for selection:
*DISABLED [0]
No action [1]
MG.33.MB.02 - VLT
13-52 SL Controller Action
Array [20]
Option:
[2] Select set-up 1 Select set-up 1 [2] - changes the active set-up
[3] Select set-up 2 Select set-up 2 [3] - changes the active set-up
[4] Select set-up 3 Select set-up 3 [4] - changes the active set-up
[5] Select set-up 4 Select set-up 4 [5] - changes the active set-up
[10] Select preset
ref 0
[11] Select preset
ref 1
[12] Select preset
ref 2
[13] Select preset
ref 3
[14] Select preset
ref 4
®
is a registered Danfoss trademark
Function:
(0-10 Active Set-up) to '1'.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a fieldbus.
0-10 Active Set-up) to '2'.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a fieldbus.
(0-10 Active Set-up) to '3'.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a fieldbus.
(0-10 Active Set-up) to '4'.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a fieldbus.
Select preset reference 0 [10] – selects preset
reference 0.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Select preset reference 1 [11] – selects preset
reference 1.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Select preset reference 2 [12] – selects preset
reference 2.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Select preset reference 3 [13] – selects preset
reference 3.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Select preset reference 4 [14] – selects preset
reference 4.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
