Parameter Descriptions
3.13.3 12-2* Process Data
12-20 Control Instance
Range:
[None, 20, 21, 100,
3 3
101, 103]
12-21 Process Data Config Write
Range:
[[0 - 9] PCD read 0 - 9] Configuration of readable process
NOTE
For configuration of 2-word (32-bit) parameter read/write,
use 2 consecutive arrays in 12-21 Process Data Config Write
and 12-22 Process Data Config Read.
12-22 Process Data Config Read
Range:
[[0 - 9] PCD read 0 - 9] Configuration of readable process
12-23 Process Data Config Write Size
Range:
16 [1 - 32 ] Sets the number of bits being sent from the drive
*
12-24 Process Data Config Read Size
Range:
16 [1 - 32 ] Sets the number of bits being sent to the drive as
*
12-27 Primary Master
Range:
0 [0 -
*
4294967295 ]
122
FC 300 Programming Guide
Function:
Read only. Displays the originator-to-
target connection point. If no CIP
connection is present "None" is displayed.
Function:
data.
Function:
data.
Function:
as process data. The setting counts from right
(LSB). The value 1 means that only the least
significant bit of the signal will be transferred from
the drive.
Function:
process data. The setting counts from right (LSB).
The value 1 means that only the least significant bit
of the signal will be transferred to the drive. The
preceding bits will be set to zero.
Function:
Controls the Master's access to the process
data. The value zero (0.0.0.0) means that
other masters can take control of the drive
immediately if the connection is lost or
closed. Setting an IP number means that only
a master with this value can establish a
connection for controlling the drive. In
systems with backup masters, this parameter
should be left to the value zero (0.0.0.0).
MG.33.MB.02 - VLT
12-28 Store Data Values
Option: Function:
This parameter activates a function that stores all
parameter values in the non-volatile memory
(EEPROM) thus retaining parameter values at
power-down.
The parameter returns to "Off".
[0] Off The store function is inactive.
*
[1] Store All All parameter value will be stored in the non-
set-ups volatile memory, in all four setups.
12-29 Store Always
Option: Function:
Activates function that will always store received
parameter data in non-volatile memory (EEPROM).
[0] Off
*
[1] On
3.13.4 12-3* EtherNet/IP
12-30 Warning parameter
Range: Function:
[0000 – Read only. Displays the EtherNet/IP specific 16-bit
FFFF hex] Status-word.
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
12-31 Net Reference
Option: Function:
Read only. Displays the reference source in Instance
21/71.
[0] Off Reference from the network is not active.
*
[1] On Reference from the network is active.
®
is a registered Danfoss trademark
Description
Owned
Not used
Configured
Not used
Not used
Not used
Not used
Not used
Minor recoverable fault
Minor unrecoverable fault
Major recoverable fault
Major unrecoverable fault
Not used
Not used
Not used
Not used
