Parameter Descriptions
8-52 DC Brake Select
Option:
[0] Digital
3 3
input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-53 Start Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND Activates Start command via the fieldbus/serial
[3] Logic OR
*
8-54 Reversing Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND
[3] Logic OR
*
108
FC 300 Programming Guide
Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
Activates Start command via a digital input.
Activates Start command via the serial
communication port or fieldbus option.
Activates Start command via the fieldbus/serial
communication port, AND additionally via one
of the digital inputs.
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the fieldbus.
Activates Start command via a digital input.
Activates Start command via the serial
communication port or fieldbus option.
communication port, AND additionally via one
of the digital inputs.
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Select control of the frequency converter
reverse function via the terminals (digital input)
and/or via the fieldbus.
Activates the Reverse command via the serial
communication port or fieldbus option.
Activates the Reverse command via the
fieldbus/serial communication port, AND
additionally via one of the digital inputs.
Activates the Reverse command via the
fieldbus/serial communication port OR via one
of the digital inputs.
MG.33.MB.02 - VLT
8-55 Set-up Select
Option: Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the fieldbus.
[0] Digital Activates the set-up selection via a digital input.
input
[1] Bus Activates the set-up selection via the serial
communication port or fieldbus option.
[2] Logic AND Activates the set-up selection via the fieldbus/
serial communication port, AND additionally via
one of the digital inputs.
[3] Logic OR Activate the set-up selection via the fieldbus/
*
serial communication port OR via one of the
digital inputs.
8-56 Preset Reference Select
Option: Function:
Select control of the frequency converter Preset
Reference selection via the terminals (digital
input) and/or via the fieldbus.
[0] Digital Activates Preset Reference selection via a digital
input input.
[1] Bus Activates Preset Reference selection via the
serial communication port or fieldbus option.
[2] Logic AND Activates Preset Reference selection via the
fieldbus/serial communication port, AND
additionally via one of the digital inputs.
[3] Logic OR Activates the Preset Reference selection via the
*
fieldbus/serial communication port OR via one
of the digital inputs.
8-57 Profidrive OFF2 Select
Select control of the drive OFF2 selection via the terminals (digital
input) and/or via the fieldbus. This parameter is active only when
par. 8-01 Control Site is set to [0] Digital and ctrl. word and par.
8-10 is set to [1] Profidrive profile.
Option:
[0] Digital input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-58 Profidrive OFF3 Select
Select control of the drive OFF3 selection via the terminals (digital
input) and/or via the fieldbus. This parameter is active only when
par. 8-01 Control Site is set to [0] Digital and control word and par.
8-10 is set to [1] Profidrive profile.
Option:
[0] Digital input
[1] Bus
[2] Logic AND
[3] Logic OR
*
®
