How to Programme

2.1.9 Main Menu Mode

2 2 Start the Main Menu mode by pressing the [Main Menu] key.
The read-out shown to the right appears on the display.
The middle and bottom sections on the display show a list of
parameter groups which can be chosen by toggling the up
and down buttons.
Each parameter has a name and number which remain the
same regardless of the programming mode. In the Main
Menu mode, the parameters are divided into groups. The
first digit of the parameter number (from the left) indicates
the parameter group number.
All parameters can be changed in the Main Menu. However,
depending on the choice of configuration (1-00 Configu-
ration Mode), some parameters can be "missing". E.g. open
loop hides all the PID parameters, and other enabled options
make more parameter groups visible.

2.1.10 Parameter Selection

In the Main menu mode, the parameters are divided into
groups. Select a parameter group with the navigation keys.
The following parameter groups are accessible:
After selecting a par. group, choose a parameter by means of
the navigation keys.
The middle section on the display shows the parameter
number and name as well as the selected parameter value.
18
FC 300 Programming Guide
1107 RPM 3.84 A
Main menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
740RPM 10.64A
Basic Settings
0 -01 Language
[0] English
MG.33.MB.02 - VLT
2.1.11 Changing Data
The procedure for changing data is the same whether you
select a parameter in the Quick menu or the Main menu
mode. Press [OK] to change the selected parameter.
The procedure for changing data depends on whether the
selected parameter represents a numerical data value or a
text value.
1 (1)
2.1.12 Changing a Text Value
If the selected parameter is a text value, change the text
value with the [
The up key increases the value, and the down key decreases
the value. Place the cursor on the value you want to save and
press [OK].
2.1.13 Changing a Group of Numeric Data
Values
If the chosen parameter represents a numeric data value,
change the chosen data value by means of the [
navigation keys as well as the [
◀ ▶
[ ] [ ] navigation keys to move the cursor horizontally.
1 [1]
0-0 *
▲ ▼
Use the [ ] [ ] navigation keys to change the data value. The
up key enlarges the data value, and the down key reduces
the data value. Place the cursor on the value you want to
save and press [OK].
®
is a registered Danfoss trademark
▲ ▼
] [ ] navigation keys.
740RPM 10.64 A
Basic Settings
0 -01 Language
[0] English
▲ ▼
] [ ] navigation keys. Use the
113 RPM 1.78 A
Load depen. setting
1 - 60 Low speed load
compensation
100%
729RPM 6.21A
Load depen. setting
1 - 60 Low speed load
compensation
1 0% 6
1 [1]
0-0 *
◀ ▶
] [ ]
1(1)
1- 6*
1(1)
1- 6*
