How to Programme
2 2
1
2
Menu
On
3
Warn.
Alarm
Hand
4
on
Status Mode
Displays the status of the frequency converter or the motor.
If an alarm occurs the NLCP automatically switches to status
mode.
A number of alarms can be displayed.
NOTE
Parameter copy is not possible with LCP 101 Numerical Local
Control Panel.
20
FC 300 Programming Guide
Setup
Status Quick Main
Setup Menu
OK
Auto
Reset
O
on
22.8
A 17
MG.33.MB.02 - VLT
Main Menu/ Quick Setup is used for programming all
parameters or only the parameters in the Quick Menu (see
also description of the LCP 102 earlier in this chapter).
The parameter values can be changed using the [
when the value is flashing.
Select Main Menu by pressing [Menu] key a number of times.
Select the parameter group [xx-__] and press [OK]
Select the parameter [__-xx] and press [OK]
If the parameter is an array parameter select the array
number and press [OK]
Select the wanted data value and press [OK]
Parameters with functional choices display values such as [1],
[2], etc. For a description of the different choices, see the
individual description of the parameters in the Parameter
Selection section
[Back] for stepping backwards
▲ ▼
Arrow [ ] [ ] keys are used for manoeuvring between
commands and within parameters.
P 2-03
M enu
rpm
Setup 1
Setup 1
®
is a registered Danfoss trademark
S etup 1
S ta tus Q uick M ain
S etup M enu
▲ ▼
] [ ] keys
