Danfoss VLT AutomationDrive FC 300 Programming Manual page 81

Parameter Descriptions
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB 113),
Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6] (MCB 105),
Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
3 3
Option:
[20] Above feedback,
high
[21] Thermal warning
[22] Ready,no thermal W Frequency converter is ready for
[23] Remote,ready,no TW Frequency converter is ready for
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake war Brake is active and there are no
[29] Brake ready, no fault Brake is ready for operation and there
[30] Brake fault (IGBT)
[31] Relay 123
[32] Mech brake ctrl
80
FC 300 Programming Guide
Function:
Feedback is above the limit set in
4-57 Warning Feedback High.
Thermal warning turns on when the
temperature exceeds the limit either
in motor, frequency converter, brake
resistor, or connected thermistor.
operation and there is no over-
temperature warning.
operation and is in Auto On mode.
There is no over-temperature warning.
Frequency converter is ready for
operation and the mains voltage is
within the specified voltage range
(see General Specifications section in
Design Guide).
Logic '1' when CW rotation of the
motor. Logic '0' when CCW rotation of
the motor. If the motor is not rotating
the output will follow the reference.
Active communication (no time-out)
via the serial communication port.
Use in performing a coasted stop and
frequency converter in torque limit
condition. If the frequency converter
has received a stop signal and is in
torque limit, the signal is Logic '0'.
warnings.
are no faults.
Output is Logic '1' when the brake
IGBT is short-circuited. Use this
function to protect the frequency
converter if there is a fault on the
brake module. Use the digital output/
relay to cut out the main voltage from
the frequency converter.
Digital output/relay is activated when
Control Word [0] is selected in
parameter group 8-**.
Selection of mechanical brake control.
When selected parameters in
parameter group 2-2* are active. The
output must be reinforced to carry the
MG.33.MB.02 - VLT
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB 113),
Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6] (MCB 105),
Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[33] Safe stop active
[36] Control word bit 11 Activate relay 1 by control word from
[37] Control word bit 12 Activate relay 2 FC 302 only) by
[38] Motor feedback
error
[39] Tracking error
[40] Out of ref range
[41] Below reference,
low
[42] Above ref, high
[43] Extended PID Limit
[45] Bus ctrl.
[46] Bus ctrl, 1 if timeout Controls output via bus. The state of
®
is a registered Danfoss trademark
Function:
current for the coil in the brake.
Usually solved by connecting an
external relay to the selected digital
output.
(FC 302 only) Indicates that the safe
stop on terminal 37 has been
activated.
fieldbus. No other functional impact in
the frequency converter. Typical
application: controlling auxiliary
device from fieldbus. The function is
valid when FC profile [0] in
8-10 Control Word Profile is selected.
control word from fieldbus. No other
functional impact in the frequency
converter. Typical application:
controlling auxiliary device from
fieldbus. The function is valid when FC
profile [0] in 8-10 Control Word Profile
is selected.
Failure in the speed feedback loop
from motor running in closed loop.
The output can eventually be used to
prepare switching the drive in open
loop in emergency case.
When the difference between
calculated speed and actual speed in
4-35 Tracking Error is larger than
selected the digital output/relay is
active.
Active when the actual speed is
outside settings in 4-52 Warning Speed
Low to 4-55 Warning Reference High.
Active when actual speed is below
speed reference setting.
Active when actual speed is above
speed reference setting.
Controls digital output/relay via bus.
The state of the output is set in
5-90 Digital & Relay Bus Control. The
output state is retained in the event of
bus time-out.
the output is set in 5-90 Digital & Relay
