How to Programme
NOTE
Stop the motor before performing this operation.
2 2
You can now connect the LCP to another frequency
converter and copy the parameter settings to this frequency
converter as well.
Data transfer from LCP to frequency converter
1. Go to 0-50 LCP Copy
2. Press the [OK] key
3. Select "All from LCP"
4. Press the [OK] key
The parameter settings stored in the LCP are now transferred
to the frequency converter indicated by the progress bar.
When 100% is reached, press [OK].
NOTE
Stop the motor before performing this operation.

2.1.4 Display Mode

In normal operation, up to 5 different operating variables can
be indicated continuously in the middle section: 1.1, 1.2, and
1.3 as well as 2 and 3.

2.1.5 Display Mode - Selection of Read-Outs

It is possible to toggle between three status read-out screens
by pressing the [Status] key.
Operating variables with different formatting are shown in
each status screen - see below.
The table shows the measurements you can link to each of
the operating variables. When Options are mounted,
additional measurements are available. Define the links via
0-20 Display Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large, and
0-24 Display Line 3 Large.
Each readout parameter selected in 0-20 Display Line 1.1
Small to 0-24 Display Line 3 Large has its own scale and digits
after a possible decimal point. By larger numeric value of a
parameter fewer digits are displayed after the decimal point.
Ex.: Current readout 5.25A; 15.2A 105A.
14
FC 300 Programming Guide
Operating variable:
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference [%]
16-03 Status Word
16-05 Main Actual Value [%]
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor Current
16-16 Torque [Nm]
16-17 Speed [RPM]
16-18 Motor Thermal
16-20 Motor Angle
16-30 DC Link Voltage
16-32 Brake Energy /s
16-33 Brake Energy /2 min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-36 Inv. Nom. Current
16-37 Inv. Max. Current
16-38 SL Controller State
16-39 Control Card Temp.
16-40 Logging Buffer Full
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-53 Digi Pot Reference
16-60 Digital Input
16-61 Terminal 53 Switch Setting
16-62 Analog Input 53
16-63 Terminal 54 Switch Setting
16-64 Analog Input 54
16-65 Analog Output 42 [mA]
16-66 Digital Output [bin]
16-67 Pulse Input #29 [Hz]
16-68 Freq. Input #33 [Hz]
16-69 Pulse Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
16-71 Relay Output [bin]
16-72 Counter A
16-73 Counter B
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1
16-84 Comm. Option STW
16-85 FC Port CTW 1
16-86 FC Port REF 1
16-90 Alarm Word
16-92 Warning Word
16-94 Ext. Status Word
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
Unit:
hex
[unit]
%
hex
%
[kW]
[HP]
[V]
[Hz]
[A]
Nm
[RPM]
%
V
kW
kW
C
%
A
A
C
[Unit]
bin
V
V
[mA]
[bin]
[Hz]
[Hz]
[Hz]
[Hz]
hex
hex
hex
hex
hex
