3.9 Parameters: 7-** Controllers

3.9.1 7-0* Speed PID Ctrl.
7-00 Speed PID Feedback Source
Option: Function:
Select the encoder for closed loop
feedback.
The feedback may come from a
different encoder (typically mounted
on the application itself) than the
motor mounted encoder feedback
selected in 1-02 Flux Motor Feedback
Source.
This parameter cannot be adjusted
while the motor is running.
[0] Motor feedb. P1-02
*
[1] 24V encoder
[2] MCB 102
[3] MCB 103
[4] MCO Encoder 1 X56
[5] MCO Encoder 2 X55
[6] Analog input 53
[7] Analog input 54
[8] Frequency input 29
[9] Frequency input 33
NOTE
If separate encoders are used (FC 302 only) the ramp settings
parameters in the following groups: 3-4*, 3-5*, 3-6*, 3-7* and
3-8* must be adjusted according to the gear ratio between
the two encoders.
7-02 Speed PID Proportional Gain
Range: Function:
Application [0.000 - Enter the speed controller proportional
dependent 1.000 ] gain. The proportional gain amplifies
*
the error (i.e. the deviation between the
feedback signal and the set-point). This
parameter is used with 1-00 Configu-
ration Mode Speed open loop [0] and
Speed closed loop [1] control. Quick
control is obtained at high amplifi-
cation. However if the amplification is
too great, the process may become
unstable.
Use this parameter for values with three
decimals. For a selection with four
decimals, use 3-83 Quick Stop S-ramp
Ratio at Decel. Start.
FC 300 Programming Guide
7-03 Speed PID Integral Time
Range:
Application
dependent
7-04 Speed PID Differentiation Time
Range:
Application
dependent
7-05 Speed PID Diff. Gain Limit
Range:
5.0
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
Function:
[2.0 - Enter the speed controller integral time,
20000.0 which determines the time the internal
*
ms] PID control takes to correct errors. The
greater the error, the more quickly the
gain increases. The integral time causes
a delay of the signal and therefore a
dampening effect, and can be used to
eliminate steady state speed error.
Obtain quick control through a short
integral time, though if the integral time
is too short, the process becomes
unstable. An excessively long integral
time disables the integral action, leading
to major deviations from the required
reference, since the process regulator
takes too long to regulate errors. This
parameter is used with Speed open loop
[0] and Speed closed loop [1] control, set
in 1-00 Configuration Mode.
Function:
[0.0 - Enter the speed controller differen-
200.0 tiation time. The differentiator does not
*
ms] react to constant error. It provides gain
proportional to the rate of change of
the speed feedback. The quicker the
error changes, the stronger the gain
from the differentiator. The gain is
proportional with the speed at which
errors change. Setting this parameter to
zero disables the differentiator. This
parameter is used with 1-00 Configu-
ration Mode Speed closed loop [1]
control.
Function:
[1.0 - Set a limit for the gain provided by the differen-
*
20.0 ] tiator. Since the differential gain increases at
higher frequencies, limiting the gain may be
useful. For example, set up a pure D-link at low
frequencies and a constant D-link at higher
frequencies. This parameter is used with
1-00 Configuration Mode Speed closed loop [1]
control.
