Parameter Descriptions
5-24 Terminal X46/9 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB 113 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
5-25 Terminal X46/11 Digital Input
Option: Function:
[0] No operation This parameter is active when option
*
moduleMCB 113 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
5-26 Terminal X46/13 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB 113 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
3.7.3 5-3* Digital Outputs
The 2 solid-state digital outputs are common for terminals 27
and 29. Set the I/O function for terminal 27 in 5-01 Terminal
27 Mode, and set the I/O function for terminal 29 in
5-02 Terminal 29 Mode. These parameters cannot be adjusted
while the motor is running.
[0] No operation Default for all digital outputs and relay
outputs
[1] Control ready The control card is ready. E.g.: Feedback
from a drive where the control is supplied
by an external 24 V (MCB 107) and the
main power to drive is not detected.
[2] Drive ready The frequency converter is ready for
operation and applies a supply signal on
the control board.
[3] Drive ready / The frequency converter is ready for
remote control operation and is in [Auto on] mode.
[4] Enable / no Ready for operation. No start or stop
warning command is been given (start/disable). No
warnings are active.
[5] VLT running Motor is running and shaft torque present.
[6] Running / no Output speed is higher than the speed set
warning in 1-81 Min Speed for Function at Stop
[RPM]. The motor is running and there are
no warnings.
[7] Run in range / Motor is running within the programmed
no warning current and speed ranges set in
4-50 Warning Current Low to 4-53 Warning
Speed High. There are no warnings.
[8] Run on Motor runs at reference speed. No
reference / no warnings.
warning
FC 300 Programming Guide
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
Alarm An alarm activates the output. There are
no warnings.
Alarm or An alarm or a warning activates the
warning output.
At torque limit The torque limit set in 4-16 Torque Limit
Motor Mode or 4-17 Torque Limit Generator
Mode has been exceeded.
Out of current The motor current is outside the range set
range in 4-18 Current Limit.
Below current, Motor current is lower than set in
low 4-50 Warning Current Low.
Above current, Motor current is higher than set in
high 4-51 Warning Current High.
Out of range Output frequency is outside the frequency
range set in 4-52 Warning Speed Low and
4-53 Warning Speed High.
Below speed, Output speed is lower than the setting in
low 4-52 Warning Speed Low.
Above speed, Output speed is higher than the setting in
high 4-53 Warning Speed High.
Out of feedback Feedback is outside the range set in
range 4-56 Warning Feedback Low and
4-57 Warning Feedback High.
Below feedback Feedback is below the limit set in
low 4-56 Warning Feedback Low.
Above Feedback is above the limit set in
feedback high 4-57 Warning Feedback High.
Thermal The thermal warning turns on when the
warning temperature exceeds the limit in the
motor, the frequency converter, the brake
resistor, or the thermistor.
Ready, no Frequency converter is ready for operation
thermal and there is no over-temperature warning.
warning
Remote, ready, Frequency converter is ready for operation
no thermal and is in [Auto on] mode. There is no over-
warning temperature warning.
Ready, no Frequency converter is ready for operation
over-/ under and the mains voltage is within the
voltage specified voltage range (see General
Specifications section in the Design Guide).
Reverse Reversing. Logic '1' when CW rotation of
the motor. Logic '0' when CCW rotation of
the motor. If the motor is not rotating the
output will follow the reference.
Bus OK Active communication (no time-out) via
the serial communication port.
Torque limit Use in performing a coasting stop and in
and stop torque limit condition. If the frequency
converter has received a stop signal and is
at the torque limit, the signal is Logic '0'.
Brake, no brake Brake is active and there are no warnings.
warning
Brake ready, no Brake is ready for operation and there are
fault no faults.
