Parameter Descriptions
0-20 Display Line 1.1 Small
Option:
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
*
[1618] Motor Thermal
[1619] KTY sensor
temperature
[1620] Motor Angle
[1621] Torque [%] High Res.
[1622] Torque [%]
[1625] Torque [Nm] High
[1630] DC Link Voltage
[1632] Brake Energy /s
[1633] Brake Energy /2 min
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1638] SL Controller State
[1639] Control Card Temp.
[1650] External Reference
FC 300 Programming Guide
Function:
Voltage supplied to the motor.
Motor frequency, i.e. the output
frequency from the frequency
converter in Hz
Phase current of the motor
measured as effective value.
Motor frequency, i.e. the output
frequency from the frequency
converter in percent.
Actual motor torque in Nm
Speed in RPM (revolutions per
minute) i.e. the motor shaft speed
in closed loop.
Thermal load on the motor,
calculated by the ETR function.
Present motor load as a
percentage of the rated motor
torque.
Intermediate circuit voltage in
the frequency converter.
Present brake power transferred
to an external brake resistor.
Stated as an instantaneous value.
Brake power transferred to an
external brake resistor. The mean
power is calculated continuously
for the most recent 120 seconds.
Present heat sink temperature of
the frequency converter. The cut-
out limit is 95 ±5° C; cutting back
in occurs at 70 ±5° C.
Percentage load of the inverters.
Nominal current of the frequency
converter.
Maximum current of the
frequency converter.
State of the event executed by
the control.
Temperature of the control card.
Sum of the external reference as
a percentage, i.e. the sum of
analog/pulse/bus.
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
0-20 Display Line 1.1 Small
Option:
[1651] Pulse Reference
[1652] Feedback [Unit]
[1653] Digi Pot Reference
[1657] Feedback [RPM]
[1660] Digital Input
[1661] Terminal 53 Switch
Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch
Setting
[1664] Analog Input 54
[1665] Analog Output 42
[mA]
[1666] Digital Output [bin]
[1667] Freq. Input #29 [Hz]
[1668] Freq. Input #33 [Hz]
[1669] Pulse Output #27 [Hz] Actual value of impulses applied
[1670] Pulse Output #29 [Hz] Actual value of impulses applied
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1674] Prec. Stop Counter
[1675] Analog In X30/11
Function:
Frequency in Hz connected to the
digital inputs (18, 19 or 32, 33).
Reference value from
programmed digital input(s).
Signal states form the 6 digital
terminals (18, 19, 27, 29, 32 and
33). There are 16 bits in total, but
only six of them are used. Input
18 corresponds to the leftmost of
the used bits. Signal low = 0;
Signal high = 1.
Setting of input terminal 54.
Current = 0; Voltage = 1.
Actual value at input 53 either as
a reference or protection value.
Setting of input terminal 54.
Current = 0; Voltage = 1.
Actual value at input 54 either as
reference or protection value.
Actual value at output 42 in mA.
Use 6-50 Terminal 42 Output to
select the value to be shown.
Binary value of all digital outputs.
Actual value of the frequency
applied at terminal 29 as an
impulse input.
Actual value of the frequency
applied at terminal 33 as an
impulse input.
to terminal 27 in digital output
mode.
to terminal 29 in digital output
mode.
Application dependent (e.g. SLC
Control)
Application dependent (e.g. SLC
Control)
Display the actual counter value.
Actual value at input X30/11
either as reference or protection
value.
