Danfoss VLT AutomationDrive FC 300 Programming Manual page 31

Parameter Descriptions
0-30 Unit for User-defined Readout
Option:
[1] %
[5] PPM
[10] 1/min
3 3
[11] rpm
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
30
FC 300 Programming Guide
Function:
MG.33.MB.02 - VLT
0-31 Min Value of User-defined Readout
Range:
0.00 CustomRea- [Application
doutUnit dependant]
*
0-32 Custom Readout Max Value
Range:
100.00 Custom- [par. 0-31 -
ReadoutUnit 999999.99
*
CustomRea-
doutUnit]
0-37 Display Text 1
Range: Function:
0 [0 - 0 ] Enter a text which can be viewed in the graphical
*
display by selecting Display Text 1 [37] in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small, 0-22 Display
Line 1.3 Small, 0-23 Display Line 2 Large or 0-24 Display
Line 3 Large.
0-38 Display Text 2
Range: Function:
0 [0 - 0 ] Enter a text which can be viewed in the graphical
*
display by selecting Display Text 2 [38] in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small, 0-22 Display
Line 1.3 Small, 0-23 Display Line 2 Large or 0-24 Display
Line 3 Large.
0-39 Display Text 3
Range: Function:
0 [0 - 0 ] Enter a text which can be viewed in the graphical
*
display by selecting Display Text 3 [39] in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small, 0-22 Display
Line 1.3 Small, 0-23 Display Line 2 Large or 0-24 Display
Line 3 Large.
®
is a registered Danfoss trademark
Function:
This parameter sets the min.
value of the custom defined
readout (occurs at zero speed).
Only possible to set different
from 0 is when selecting a
linear unit in 0-30 Unit for User-
defined Readout. For Quadratic
and Cubic units the minimum
value will be 0.
Function:
This parameter sets the max
value to be shown when the
speed of the motor has
reached the set value for
4-13 Motor Speed High Limit
[RPM] or 4-14 Motor Speed
High Limit [Hz] (depends on
setting in 0-02 Motor Speed
Unit).
